Fisher FieldVue DVC6200 Smart Valve Positioner with HART Communication

1
MOQ
US $1500.00 - 2000.00/ Set
Prix
Fisher FieldVue DVC6200 Smart Valve Positioner with HART Communication
traits Galerie Description de produit Demandez une citation
traits
Caractéristiques
Communication Protocol: 4-20 mA HART
Diagnostics: Yes
Max Outlet Pressure: 145 psig
Operating Temperature: Standard Temperature, High Temperature
Mettre en évidence:

Fisher DVC6200 HART valve positioner

,

smart valve positioner with HART

,

pneumatic control valve positioner
Informations de base
Nom de marque: Fisher
Model Number: DVC6200
Documents: xiangjing valve&instrument ...t .pdf
Conditions de paiement et expédition
Packaging Details: Cardboard box + protection
Delivery Time: 35-60 days
Payment Terms: T/T
Supply Ability: 2000 set per year
Description de produit
Fisher FieldVue DVC6200 Smart Valve Positioner

Advanced pneumatic control device designed for precise regulation of industrial valves, including black water angle valves and sliding-stem actuators.

Product Attributes
Attribute Value
Communication Protocol 4-20 mA HART
Diagnostics Yes
Max Outlet Pressure 145 psig
Operating Temperature Standard Temperature, High Temperature
Technical Specifications
Parameter Specification
Input Signal 4-20 mA DC (HART 5/7 compatible)
Pneumatic Output 1/4 NPT, 0.056-29.5 m³/hr (2.1-1100 scfh)
Supply Pressure Range 1.4-5.5 bar (20-80 psig)
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Protection Rating IP66 / NEMA 4X
Communication Protocol HART 5/7, Multi-drop Network
Accuracy ±1% of Travel Span
Hazardous Area Approvals ATEX, IECEx, CSA, FM, Lloyd's Register
Key Features
  • Digital Intelligence: HART communication for remote configuration and monitoring via Fisher ValveLink software.
  • Linkless Feedback System: Reduces mechanical wear in vibratory environments.
  • Self-Diagnostics: Monitors valve stem travel, air pressure, and electronics.
  • Modular Design: Easy component replacement without field wiring disruption.
  • Environmental Resistance: IP66-rated housing for dust, moisture, and extreme temperatures.
  • Energy Efficiency: Low air consumption (≤0.184 m³/hr at 80 psig) cuts operational costs.
Applications
  • Chemical & Petrochemical: Flow control in corrosive settings
  • Power Generation: Steam valve regulation for boiler efficiency
  • Water Treatment: Automation of black water angle valves in wastewater systems
  • Oil & Gas: ESD valve control in offshore platforms
  • Food & Beverage: Hygienic process control for CIP/SIP systems
  • Marine & Offshore: Reliable operation under vibration and saltwater exposure
